AppleHDA

[jcgeraldi]

Mirone .... segue o meu dsdt.aml sem patch HDEF. Obrigado.

dsdt.aml.zip

[overclockthesun]

which graphics card you are using?



Hi Mirone,

I am using Intel HD 3000 onboard only. The AMD 6490M is a no go. I tried to get it working, but this horrible hp insyde bios won't let me dump the bios. Tried every method possible. Fianlly used the phoenix bios tool. Unfortunately, the dump comes up with errors. Its completely locked down. have a post about this on im but this card is not going to work. So I stick with hd 3000 only. Logicpro works fine with it so no problems for with hd 3000. Changed my famebuffers around a bit today but no luck with hdmi audio.

[jcgeraldi]

Boa tarde @Mirone .... eu resolvi refazer algumas coisas aqui e instalei novamente as Kexts e patch HDEF.

Agora o som sai no fone de ouvido e tenho esses erros .....

Waiting for DSMOS...DSMOS has arrived

Sound assertion ""ERROR: EFI ROM did not publish 'hda-gfx' associative property!\\n"" failed in "/SourceCache/AppleHDA/AppleHDA-179.1.4/AppleHDA/AppleHDACodecGeneric.cpp" at line 331 goto ExitError

Transcript Offline - Buffer Pool Allocate [181000] failed

Auth result for: b0:48:7a:c3:f5:4c MAC AUTH succeeded

AirPort: Link Up on en0

AirPort: RSN handshake complete on en0

Mini9MuteControl: setting to 0

Mini9MuteControl: done

Mini9MuteControl: setting to 0

Mini9MuteControl: done

macx_swapon SUCCESS

Sandbox: sandboxd(89) deny mach-lookup com.apple.coresymbolicationd

Mini9MuteControl: setting to 0

Mini9MuteControl: done

e anexei meu dsdt com as correcoes e o patch .....

dsdt.aml.zip

[Mirone]

@jcgeraldi

http://www.sendspace.com/file/w8tepd

Tenta essa kext+DSDT e me diga se funcionou, após instalar repare as permissões e reconstrua caches e ao invés de reiniciar deslique o notebook por 40segundos e ligue novamente.

[Mirone]

@overclockthesun

try this DSDT:DSDT.aml.zip

[overclockthesun]

@overclockthesun

try this DSDT:Install Extra.pkg.zip



Also, There was no automatic Monitor Mirroring. I have fixed that by adding "01168086" without "0x" to IOPCIPrimaymatch in AppleHD3000Graphics.kext. Now it starts with mirroring enabled. Did the same for Snbgraphics kext.

I have one question for you if you can answer it.... here is my codecgraph pic.

codec_dump_dec.txt.svg.zip

As you can see there are so many nodes ..... why is it that all the ones named N/A within the box, if I add them to pathmap just turn off audio completely? So does it mean that only nodes which are clearly labelled like for eg... node 15 (int speakers) will work? Please let me know.... I am trying to learn.

Ever since it hit me that reading the codecgraph is exactly the same as reading a Critical path method graph ....its fun now

Finally I just want to thank you once again for all your help. I understand the time you put in to help people like me out. This stuff is quite time consuming.

It took me ages to research all this. And the editing takes quite some time until you figure it out. The only thing that sped things up was Xtrafinder as I can just open a terminal window in a folder and quickly inflate and deflate the zlib files. I will pass around your help to me to the community in some form or the other by being active.

If you remember my thread for audio on tony's site, I will complete a guide tonight for the DV6 series. There are some differences in the motherboards between Probook and Dv6/7 series even though it is exactly the same ...point to be noticed is Mickey1979's codecgraph here http://imageshack.us/a/img835/7218/codecdumpdectxt.png

Will also make one with xHack on insanely.... will give you the due credit for everything you have helped me with.

Thanks once again Have good day. Will stick around this thread to practice what I have learnt.

The only thing left to do now is VGA video output. That will have to wait for a while until my monitor comes back from RMA.

Thanks again

[Mirone]

@overclockthesun

Yes, only the Active Nodes appear in Verbs.txt

All the information needed are codec_dump

have to have patience and persistence. this is a tough job.

be willing to do this welcome to the boat. Forgot to mention you editing framebuffer sorry for the failure, but makes a Toleda

Great Work around for HDMI audio. Besides its codec has an extra node

of the EDPD would 01570c02.

All the Best!

[jcgeraldi]

Bom dia @Mirone, não funcionou de nenhuma maneira ..... Testei com o dsdt e applehda e nem o som foi reconhecido. Com o meu dsdt com hdef 12, e as kexts AppleHDA.kext, IOAudioFamily.kext, LegacyHDA_ALC662-v.1.kext o som sai apenas no fone de ouvido e apresenta alguns erros no log. Vou passar alguns prints, blz ..... Obrigado ....

Sound assertion ""ERROR: EFI ROM did not publish 'hda-gfx' associative property!\\n"" failed in "/SourceCache/AppleHDA/AppleHDA-179.1.4/AppleHDA/AppleHDACodecGeneric.cpp" at line 331 goto ExitError

Auth result for: b0:48:7a:c3:f5:4c MAC AUTH succeeded

AirPort: Link Up on en0

AirPort: RSN handshake complete on en0

Mini9MuteControl: setting to 0

Mini9MuteControl: done

macx_swapon SUCCESS

Mini9MuteControl: setting to 0

Mini9MuteControl: done

Sandbox: sandboxd(89) deny mach-lookup com.apple.coresymbolicationd

Mini9MuteControl: setting to 0

Mini9MuteControl: done

[overclockthesun]

@overclockthesun

Yes, only the Active Nodes appear in Verbs.txt

All the information needed are codec_dump

have to have patience and persistence. this is a tough job.

be willing to do this welcome to the boat. Forgot to mention you editing framebuffer sorry for the failure, but makes a Toleda

Great Work around for HDMI audio. Besides its codec has an extra node

of the EDPD would 01570c02.

All the Best!



So the active nodes are all thats needed... good to know. Yeah Toleda jsut explained it in detail. Very noob friendly. However, everyhwere else if you see, the edit is to get rid off the line with 0205 completely ...thats why I couldn't get it to work before. Even on osxlatitude website, the edit called for 08 00 00 00 06 00 ....whereas in case of toledas page, there is no need for 06 00. just leave it at 07 00.

The part I am still trying to understand is this "EDPD would 01570c02" ????

I would love to help out. See ya around

PS: My username over at insanely is Ghajini08. Lol ... been around so long. Still have my old Pentium 4 running 10.5.8. Most stable system ever. Something that was built with XP in mind crashed everyday. With leopard its never crashed once in so many years. My school system

[Mirone]

@OVERCLOCKTHESUN

look here: https://www.google.com.br/url?sa=t&rct=j&q=&esrc=s&source=web&cd=1&ved=0CCwQFjAA&url=http%3A%2F%2Fwww.idt.com%2Fdocument%2Fhd-audio-eapd-application-note&ei=t6wTUuvrLYKg9QSepYHoDw&usg=AFQjCNEcneDO8Dr9M09VaEbmWSoxuOtgRw&bvm=bv.50952593,d.eWU

[overclockthesun]

@OVERCLOCKTHESUN

look here: https://www.google.com.br/url?sa=t&rct=j&q=&esrc=s&source=web&cd=1&ved=0CCwQFjAA&url=http%3A%2F%2Fwww.idt.com%2Fdocument%2Fhd-audio-eapd-application-note&ei=t6wTUuvrLYKg9QSepYHoDw&usg=AFQjCNEcneDO8Dr9M09VaEbmWSoxuOtgRw&bvm=bv.50952593,d.eWU



@Mirone,

Thanks man. Its a good read. Simple language and easy to understand at least from the first 2-3 pages. Haven't read it completely though. Time to sleep now

[aasxande]

Mirone tem como corrigir applehda sem esse dum pelo linux?

Abraço.

[Mirone]

Mirone tem como corrigir applehda sem esse dum pelo linux?

Abraço.

Não tem, o dump é essencial.

[jcgeraldi]

@Mirone, resolvi usar um notebook aqui Samsung NP300E4A-BD2BR com áudio Intel HDMI e ALC269. Você pode corrigir a AppleHDA pra mim por favor. Segue o codecdump. Obrigado pela atenção.

OBS: Testei essa kext http://www.osx86.net/downloads.php?do=file&id=4072 e editei o dsdt conforme explicado e funcionou .... mas tenho esse erro: Sound assertion "0 == hdaGfxCandidate" failed in AppleHDAController at line 1096 goto Exit

Pode me orientar como acertar isso?

CodecDump.zip

DSDT.AML.zip

Edited August 22, 2013 by Guest

[Mirone]

@Mirone, resolvi usar um notebook aqui Samsung NP300E4A-BD2BR com áudio Intel HDMI e ALC269. Você pode corrigir a AppleHDA pra mim por favor. Segue o codecdump. Obrigado pela atenção.

ja tentou essa? http://www.osx86.net/downloads.php?do=file&id=3177

[jcgeraldi]

Coloco a AppleHDA e edito DSDT com layout 1? HDAEnabler e outras alteracoes nao precisa?

[Mirone]

Coloco a AppleHDA e edito DSDT com layout 1? HDAEnabler e outras alteracoes nao precisa?

não, so editar o dsdt com layout1.

[Mirone]

@jcgeraldi

Esse erro deve ser por causa do HDMI, mas se tudo funciona você pode ignorar ele.

[overclockthesun]

Hi Mirone,

Was reading the document you linked the other day. It jsut hit me, we use layout id 12 for idt 111d7605 right? Now how do I know which layout to use for any other device? Or do we just use layoutid 12 for anything we wanna edit?

[Mirone]

Hi Mirone,

Was reading the document you linked the other day. It jsut hit me, we use layout id 12 for idt 111d7605 right? Now how do I know which layout to use for any other device? Or do we just use layoutid 12 for anything we wanna edit?

We can use 12,1,2, and 3 or any other number of kext in Lion.

From the Mountain Lion version it requires is a layout native

  before we could use to layout887 codec ALC887 kext of the Mountain Lion

this is no longer possible.
